User Manual for Williams Sound IR SY5 SoundPlus Medium-Area Wireless Infrared System with 3 Headphones Click to enlarge the picture
Contents of the user manual for the Williams Sound IR SY5 SoundPlus Medium-Area
- Product category: Components & Accessories Williams Sound
- Brand: Williams Sound
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Williams Sound Components & Accessories
 |
User manual for the Williams Sound IR SY5 SoundPlus Medium-Area contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Williams Sound product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Williams Sound user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Williams Sound product will considerably shorten its lifespan!
|
Product description The Williams Sound IR SY5 is a SoundPlus Series medium-area wireless infrared system designed to deliver reliable audio monitoring for up to three people in conferences, classrooms, assisted living facilities, and more. It includes the IR T2 infrared transmitter and its power supply, three WIR RX22-4 four-channel bodypack IR receivers, three HED 021 folding headphones, two 18" induction neckloops, six AA batteries, a wall/ceiling mount, and an ADA wall plaque. With a coverage area of up to 18,000 square feet and selectable transmission frequencies, it provides a blend of easy setup and robust power. Audio inputs to the transmitter include two Euroblock line inputs and a 3.5mm microphone input. An additional Euroblock is provided for control system integration. Back-panel green and yellow LEDs indicate power status and signal presence. A power-saving mode automatically shuts off the carrier after 12 minutes without audio. Connect the supplied headphones or neckloops to the bodypack IR receivers, which feature low-battery indicators, channel selectors, and on/off/volume controls. Use the headphones for standard on-ear monitoring or utilize the neckloops for integration of hearing aids or cochlear implants with T-coil capabilities. - IR T2 SoundPlus Medium-Area Infrared Transmitter for Assistive Listening The Williams Sound IR T2 is a two-channel, SoundPlus Series infrared transmitter designed to deliver a coverage area of up to 18,000 square feet for assistive listening and language interpretation in commercial spaces. It supports 2.3, 2.8, 3.3, and 3.8 MHz transmission frequencies with WIR RX22-4, WIR RX18, or IR R1 receivers. Line inputs are accessible via two Euroblock connectors while a 3.5mm mini jack allows the connection of a microphone, which can be optimized using the dedicated mic gain knob and microphone channel selection switch. Additionally, a control system may be integrated via a separate Euroblock port. LEDs are provided for indication of power status and signal presence. The power-saving mode automatically shuts off the carrier after 12 minutes without audio. The included wall/ceiling mount and international power supply enable flexible installation.
- Ideal for assistive listening and language interpretation in commercial spaces such as conference rooms, assisted living facilities, small cinemas/theaters, classrooms, and courtrooms
- Wall-/ceiling-mountable compact transmitter with a maximum coverage area of 18,000 ft
|
Upload User Manual
Have you got an user manual for the Williams Sound IR SY5 SoundPlus Medium-Area Wireless Infrared System with 3 Headphones in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parameters - IR T2 SoundPlus Medium-Area Infrared Transmitter for Assistive Listening
| Coverage Area | Up to 18,000 ft
Rating80% users recommend this product to others. And what about you?
This product has already been rated by 77 owners. Add your rating and experience with the product.
