User Manual for Wilson Electronics Yagi Wide Band Directional Antenna Click to enlarge the picture
Contents of the user manual for the Wilson Electronics Yagi Wide Band Directional
- Product category: Antennas & Accessories Wilson Electronics
- Brand: Wilson Electronics
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Wilson Electronics Antennas & Accessories
|
User manual for the Wilson Electronics Yagi Wide Band Directional contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Wilson Electronics product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Wilson Electronics user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Wilson Electronics product will considerably shorten its lifespan!
|
Product description Boost your cellular signal transmission by up to 10.6 dBi with the Yagi Wide Band Directional Antenna from Wilson Amplifiers. This vertically-polarized uni-directional antenna is compatible with 50-ohm amplifiers and accessories. It's designated as an outside-building, fixed-installation antenna, and, because it's uni-directional, must be pointed toward the nearest cellular signal tower to achieve the desired results and signal gain.
The Yagi Wide Band Antenna supports all carriers transmitting within the 700-2500 MHz frequency band range. The antenna is housed in a sealed, UV-stabilized, ABS plastic casing, making it weather resistant and with a wind velocity rating of up to 134 mph. It mounts on poles up to 2" in diameter. Mounting hardware is included. - Boosts cellular signal by up to 10.6 dBi
- Designed for fixed installations
- Designed to be installed outside of a building
- Mounting hardware included
UPC: 811815023548 In the Box Wilson Electronics Yagi Wide Band Directional Antenna (50 Ohms) Mounting Hardware Limited 2-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Wilson Electronics Yagi Wide Band Directional Antenna in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersWilson Electronics 314411 Specs | Compatibility | 50 ohms amplifiers and accessories | | Frequency | 700-2500 MHz | | Gain | 700-800 MHz Gain: 7.3 dBi
824-894 MHz Gain: 8.1 dBi
880-960 MHz Gain: 7.4 dBi
1710-1880 MHz Gain: 9.2 dBi
1850-1990 MHz Gain: 10.6 dBi
2110-2170 MHz Gain: 10.4 dBi | | Impedance | 50 ohms | | Power | 100 W (max) | | Radiation | Directional | | Polarization | Vertical | | Connector | N-female | | Material | Aluminum | | Front to Back Ratio | >20 dB | | Rated Wind Velocity | 134 mph | | Temperature Range | -40 to 158° F / -40 to 70° C | | Lightning Protection | DC grounded | | Horizontal Beamwidth | 70 to 90° | | Vertical Beamwidth | 85 to 110° | | Dimensions | 11.42 x 8.27 x 2.56" / 29 x 21 x 6.5 cm | | Weight | 3.31 lb / 1.5 Kg | | | | Package Weight | 2.25 lb | | Box Dimensions (LxWxH) | 16.8 x 8.7 x 3.6" |
