Product description

The Patch Verx Software from WireCAD is a standalone application that can also plug-in for WireCAD that features a number of patch bay design and designation strip tools. It allows you to create CAD accurate drawings without knowledge of CAD. You'll also be able to create jack field layouts and designation strips from numerous pre-existing templates. It can export files to DWG, DXF, PNG, JPG, and GIF formats, as well as import data from CSV files. It can print to any Windows print device.
  • Includes patch bay design and designation strip tools
  • Create jack field layouts and designation strips from a large set of pre-existing templates
  • Create CAD accurate drawings and output without knowledge of CAD. Work in easy text grids with copy, fill, and increment functions. Use one of the 90+ templates or create your own
  • Works with or without WireCAD v4 to v6. When used as a plug-in to WireCAD, Patch Verx can pull strip data from the selected project cables database. This allows you to rapidly create layout as based on actual connection data
  • Choose from many connector styles
  • Prints to any Windows print device
  • Exports to DWG, DXF, PNG, JPG, or GIF
  • Import data from CSV
  • New template wizard allows you to easily create any one or two strip jack field with any number of columns, splits, and pair combinations
