User Manual for Wohler Multi-Channel Touch-Screen Audio Monitor with Analog Interface Click to enlarge the picture
Contents of the user manual for the Wohler Multi-Channel Touch-Screen Audio Monitor with
- Product category: Rack Mount Monitors Wohler
- Brand: Wohler
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Wohler Rack Mount Monitors
 |
User manual for the Wohler Multi-Channel Touch-Screen Audio Monitor with contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Wohler product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Wohler user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Wohler product will considerably shorten its lifespan!
|
Product description Provided by third party: Wohler Technologies has been in the business of in rack monitoring for over 25 years. iAM Series re-invented this critical piece of broadcast technology for the modern media enterprise.
iAM-AUDIO is designed to be easy to operate yet powerful enough to provide high quality, intuitive monitoring of multiple signal types within a compact form factor.
iAM-AUDIO is equipped with a variety of metering options and can support Analog, AES3 and MADI inputs with additional options for AoIP formats, including Dante, Ravenna and AES67, 3G/HD/SD-SDI and a growing range of I/O via an SFP interface.
High quality touch screen panels allow for elegant and intuitive control, with simple to navigate menus and configuration. Physical front panel controls provide access to main and auxiliary volume controls, balance control and a front mounting USB port for simple software updates.
All iAM Series monitors are built with an on-board web server. Multiple units on the same network can be updated, monitored and controlled via a browser-based user interface that supports fast configuration with role-based authentication that protects critical configurations from unauthorized alteration.
With both front mounting speakers and subwoofers, the iAM-AUDIO provides powerful sound output and audio reproduction that adheres to Wohler's own strict specifications.
iAM-AUDIO can be software upgraded to support new and emerging technologies and is the perfect solution for any application that requires a compact unit for monitoring an evolving range of professional signals.
- Key Features
-
- Wohler's renowned sound quality in 1RU form factor
- Touch screen front panel for intuitive control
- Built-in speakers, headphone jack, USB and Ethernet ports
- A range of connectors, including SFP slots for future I/O
- Store and retrieve presets via USB or remote software control
- Software upgradable, future-proof platform
- API for remote control
- Compact, space-saving unit
