Product description The 7" RM-3270WS-3G2 Dual 3G/HD/SD-SDI Video Monitor from Wohler is a multi-featured in-rack 3G/HD/SD-SDI and CVBS video monitor designed for the many feeds in mobile trucks, news and transmission control rooms, duplication, and post production applications. This dual monitor comes standard with in-monitor level metering, selectable video waveform and vectorscope, safe and title markers, labeling, tally, timecode, video format, built-in color bars, and an intuitive on-screen configuration menu.Input signals are automatically detected, and up to eight of the 16 audio channels embedded in a 3G/HD/SD-SDI bit-stream may be selected for visual monitoring on eight on-screen bar graph-style level meters. A headphone jack or speaker (sold separately) can provide audible stereo monitoring of selected left and right channels. Each of the two high-resolution LCD screens can display high-definition or standard video at either 16:9 or 4:3 aspect ratio. Parameters are selected and adjusted using an on-screen display menu. - Monitor 3G/HD/SD-SDI and analog composite video signals
- Waveform and vectorscope display
- 16-Channel in-picture level metering
- Closed caption detection and display
- Labeling, tally, timecode, detected video format, safe area, and title markers display
- Ethernet configuration and control
In the Box Wohler RM-3270WS-3G2 Dual 3G/HD/SD-SDI Video Monitor (7") AC Power Cord Table of Contents
|
Upload User Manual
Have you got an user manual for the Wohler RM-3270WS-3G2 Dual 3G HD SD-SDI Video Monitor in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersWohler RM-3270WS-3G2 Specs | | | Signal Inputs | Composite 3G/HD/SD-SDI, CVBS inputs on BNC (four auto-sensing, two per screen)
RCA analog audio stereo input pairs (two per screen) | | Signal Output | 4 x 3G/HD/SD-SDI, CVBS outputs on BNC (two per screen)
2 x RCA analog audio stereo output pairs (one per screen)
1 x 3.5 mm Mini headphone jack | | | | Level Meters | On-screen 16-channel level metering | | | | Display Type | LCD TFT screens | | Number of Displays | Two | | Display Size | 7" (18 cm) Diagonal | | Viewing Area (HxV) | 6.0 × 3.5" (15.0 x 8.8 cm) | | Aspect Ratio | 16:9 Native
4:3 Selectable | | Resolution | 1024 x 600 | | Viewing Angle | 178 (H) x 178 (V) | | Pixel Pitch (HxV) | 0.1905 X 0.1905 mm | | Pixel Response | <25 ms off-on-off (black to white to black) | | Luminance | 350 cd/m^2 | | Contrast | 700:1 | | Video Format | SDI | | Color Depth | 16.7 Million | | | | Rack Height | 3 RU | | Power Consumption | 10 W | | Dimensions | 5.3 x 19.1 x 2.6" (13.3 x 48.6 x 6.7 cm) | | Weight | 6 lb (2.7 kg) | | | | Box Dimensions (LxWxH) | 24.0 x 10.0 x 7.0" |
