User Manual for Wohler RMQ-230-3G 23" Diagonal Quad Split LCD Monitor Click to enlarge the picture
Contents of the user manual for the Wohler RMQ-230-3G 23" Diagonal Quad Split
- Product category: Production Monitors Wohler
- Brand: Wohler
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Wohler Production Monitors
|
User manual for the Wohler RMQ-230-3G 23" Diagonal Quad Split contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Wohler product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Wohler user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Wohler product will considerably shorten its lifespan!
|
Product description The Wohler RMQ-230-3G 23” Diagonal Quad Split LCD Monitor allows you to simultaneously monitor 4 display screens, each with independent controls. This quad split, LED-backlit LCD display from RMQ Series is a high-performance professional monitor that supports advanced 10-bit digital processing technology.This monitor features 3D comb filter, de-interlace, accurate scaling engine, gamma correction, and color temperature adjustment. The monitor can be configured as a quad split display of 4 equal areas, as a large screen with 3 smaller views, or as a single large display screen. It is suited for use in news and transmission control rooms, program production, channel branding, and any environment that requires intensive monitoring.This 3G monitor accepts 4 auto-sensing 3G / HD / SD-SDI / CVBS BNC inputs with 3G / HD / SD-SDI loop-thru outputs, 4 analog audio pair inputs, 1 HDMI input, and 1 HDMI output. It supports waveform, vector-scope, audio de-embedding, metering of up to 16 channels, UMD, format display, and various markers.The RMQ-230-3G allows for user-defined hot key functionality for H/V delay, under-scan, on-screen display, and more. Its on-screen level meters provide audio confidence monitoring, while tally and on-screen labeling provide quick and easy signal identification. The CRT-style image controls allow video image enhancement for each screen individually. - Multi-format analog and digital audio signals
- 4 of 5 input signals (4 x SDI / CVBS, 1 x HDMI)
- Adjustment of the parameters for each channel as well as screen
- High-quality waveform or vector monitoring (for CH-1 and CH-3 in quad view)
- Embedded SDI or stereo analog audio through speakers or headphones
- Up to 16 audio bar graph meters
- Stereo analog audio line output of selected channel
- Area, safety, and center markers
- Pre-set or user-adjustable color temperature per channel
- Timecode for SD-SDI in ANC-packet form
- HDMI output for a larger display and duplicate of screen configuration
In the Box Wohler RMQ-230-3G 23" Diagonal Quad Split LCD Monitor Base Base Board with Screws Tabletop Stand Adapter (19V) Power Cord Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Wohler RMQ-230-3G 23" Diagonal Quad Split LCD Monitor in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersWohler RMQ-230-3G Specs | Display Type | TFT-LCD, LED Backlight | | Display Size | 23.00" (58.42 cm) Diagonal | | Resolution | 1920 x 1080 | | Aspect Ratio | 16:9 | | Viewing Angle | 178° (H & V) | | Luminance | 350 cd/m2 | | Colors | 16.7 million, 24-bit | | Contrast | 900:1 | | Pixel Pitch | 0.0273 (RGB-H) x 0.273 (V) | | Input Signal | 3G-SDI: 1080p50, 1080p59.94, 1080p60; HD-SDI: 1080i50, 1080i59.94, 1080i60, 720p50, 720p59.94, 720p60, 1035i59.94, 1035i60; SD-SDI: 480i59.94, 576i50; Analog Composite: PAL, NTSC | | Space requirements | 8 RU | | Power Connector | AC power adapter (100 to 240 VAC to 12 VDC) | | Power Requirements | AC power adapter connects to mains power (100 to 240 VAC ± 10%, 50/60 Hz) | | Power Consumption | 75 W | | Dimensions (W x H x D) | 21.85 x 13.75 x 2.75" (55.50 x 34.93 x 6.99 cm) | | Weight | 17.00 lb (7.71 kg) |
