User manual
Wooden Camera Fixed Kit for Sony

User Manual for Wooden Camera Fixed Kit for Sony F5 F55

• Product category: Camcorder Supports & Rigs Wooden Camera
• Brand: Wooden Camera
• Description and content of package
• Technical information and basic settings
• Frequently asked questions – FAQ
• Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
• Authorized service for Wooden Camera Camcorder Supports & Rigs

Product description

• Fixed Base for Sony F55 & F5
  • Product Demo
  The Fixed Base for Sony F55 & F5 from Wooden Camera provides LWS 15mm pass-through rod support at the correct lens height. The baseplate can attach to any tripod plate or ARRI standard bridge plate, such as Wooden Camera's 19mm or 15mm Studio Bridge Plates. When rods are not needed, a separately-available Dovetail Clamp can be added instead to interface with 2060 Dovetails, Safety Dovetails, or Shoulder Rigs.
  • • 1/4"-20 and 3/8"-16 holes on sides for attaching accessories
    • 1/4"-20 and 3/8"-16 holes on bottom for attaching to tripod or bridge plate
    • Optional GO Shoulder low-profile shoulder pad and optional Rosette Bracket available
• Top Plate for Sony F55 & F5 Cameras The Wooden Camera Top Plate is a top cheeseplate for the Sony F55 and F5 Cameras that contours to the shape of the camera body and leaves the vent area open. Hence, the original Sony focus hook can remain attached to the camera. The stopper screw in the front prevents accidental unlocking of the FZ mount. The plate provides rows of 1/4"-20 and 3/8"-16 holes for attaching handles, UVF Mount v2, rod clamps, and more. Additional screw holes allow attachment of the original Sony F55 handle.
  • 1/4" threads in standard spacing (9mm center to center)
  • 3/8" threads in ARRI standard spacing (50mm center to center)
  UPC: 700987993493
• WC-153900 Top Handle (Cheese) The Wooden Camera WC-153900 Top Handle (Cheese) is used for securely carrying and stabilizing the camera during hand-held shooting. It bolts on to two 1/4-20 holes spaced 1.4" (36mm) apart center. The cheese grip handle bar features an array of 1/4-20 and 3/8-16 holes in standard spacing for accessory mounting. UPC: 610079105713

• 2 x 3/8"-16 Low-Profile Screw

• Limited 1-Year Warranty

• 1/4" to 20 x 3/8" Socket Cap Screw

• Limited 1-Year Warranty

• 2 x 1/4-20 x 1/2" Screw

• 1-Year Warranty

Upload User Manual

Please enter here the link to the user manual of this product: OR Enter here the file with the user manual of this product from your computer/phone: (60MB max; Permitted formats: PDF) 0%

Technical parameters

• Fixed Base for Sony F55 & F5

  Camera Mount Screw Sizes	3/8"-16
  Accessory Mounting Threads	1/4"-20 & 3/8"-16
  Dimensions	2.9 x 4.3 x 1.7" (73.6 x 110 x 42.8 mm)
  Weight	11.9 oz (338 g)

• Top Plate for Sony F55 & F5 Cameras

  Box Dimensions (LxWxH)	7.2 x 3.6 x 0.2"

• WC-153900 Top Handle (Cheese)

  Dimensions	4.8 x 2.7 x 1.9" (121.92 x 6.86 x 4.82 mm)
  Weight	0.4 lb (181.43 g)

  Box Dimensions (LxWxH)	7.7 x 4.35 x 2.3"
