Wooden Camera Panasonic GH4 Basic Accessory

User Manual for Wooden Camera Panasonic GH4 Basic Accessory Kit

• Product category: DSLR Video Supports & Rigs Wooden Camera
• Brand: Wooden Camera
• Description and content of package
• Technical information and basic settings
• Frequently asked questions – FAQ
• Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
• Authorized service for Wooden Camera DSLR Video Supports & Rigs

Product description

• Quick Cage for DSLR (Small) The small Wooden Camera Quick Cage for DSLR is a quick-release, height-adjustable cage that fits small-sized DSLR or mirrorless cameras, such as the Sony a7 series, Canon 60D, Nikon D7200, and Panasonic GH4. Your camera cage mounts securely in the case via a low profile 1/4"-20 screw on bottom and a shoe pinch on top. Sporting a minimalist design, the cage maintains access to all vital controls on the sides and rear of the camera, including flip-out and articulating LCD screens. Threaded 1/4"-20 and 3/8"-16 holes on the arm and top of the cage enable you to attach a variety of accessories. The cage includes a quick-release dovetail plate to attach to tripod plates, existing 15mm support bases, or any ARRI standard bridge plate.
  Key Features
  • • Height-adjustable camera cage for small-sized DSLRs or mirrorless
    • 1/4"-20 and 3/8"-16 accessory threads on top plate and side arm
    • 1/4"-20 camera screw and shoe pinch for secure camera mounting
    • Maintains access to vital camera controls and rear LCD screen
    • Quick-release dovetail plate (compatible with ARRI standard bridge plates)
• DSLR 15mm Base The DSLR 15mm Base from Wooden Camera is a height-adjustable baseplate attachment that provides 15mm lightweight rods at the correct lens height for DSLR cameras when combined with the Quick Cage (DSLR, Small) and Quick Cage (DSLR, Medium). The baseplate can attach to any tripod plate or ARRI standard bridgeplate. Note: Quick Cage (Small and Medium) are sold separately.
• 15mm Support Rod (12") This is a single, 12" long 15mm Support Rod from Wooden Camera for mounting accessories. It is chamfered at each end to ease sliding accessories on and off, and has a hollow interior providing for maximum strength. UPC: 610079106123
• WC-153900 Top Handle (Cheese) The Wooden Camera WC-153900 Top Handle (Cheese) is used for securely carrying and stabilizing the camera during hand-held shooting. It bolts on to two 1/4-20 holes spaced 1.4" (36mm) apart center. The cheese grip handle bar features an array of 1/4-20 and 3/8-16 holes in standard spacing for accessory mounting. UPC: 610079105713

• Quick-Release Dovetail Plate

• 1/4"-20 Low Profile Screw

• Limited 1-Year Warranty

• 2 x 1/4" to 20 x 1/2" Socket Cap Screw

• Limited 1-Year Warranty

• Limited 1-Year Warranty

• 2 x 1/4-20 x 1/2" Screw

• 1-Year Warranty

Also Includes

• Limited 1-Year Warranty

Upload User Manual

Please enter here the link to the user manual of this product: OR Enter here the file with the user manual of this product from your computer/phone: (60MB max; Permitted formats: PDF) 0%

Technical parameters

• Quick Cage for DSLR (Small)

  Accessory Mount Threads	1/4"-20 holes in standard spacing (9 mm center to center) 3/8"-16 holes in ARRI standard spacing (50 mm center to center)
  Dimensions	4.9 x 4.8 x 4.2" (12.36 x 12.22 x 10.78 cm)
  Weight	1 lb (472 g)

  Box Dimensions (LxWxH)	6.0 x 5.0 x 0.2"

• DSLR 15mm Base

  Box Dimensions (LxWxH)	4.3 x 4.3 x 1.1"

• 15mm Support Rod (12")

  Rod Size	15 mm
  Rod Length	12" (30.5 cm)

  Box Dimensions (LxWxH)	12.05 x 1.35 x 0.6"

• WC-153900 Top Handle (Cheese)

  Dimensions	4.8 x 2.7 x 1.9" (121.92 x 6.86 x 4.82 mm)
  Weight	0.4 lb (181.43 g)

  Box Dimensions (LxWxH)	7.7 x 4.35 x 2.3"
