Product description

• Top Mount (Red One) The Top Mount (Red One) from Wooden Camera provides rows of 1/4"-20 holes in RED standard spacing allowing Rod Clamps, Handles, Battery Mounts, Safety NATO Rails, UVF Mount, and more to be attached. Additional 3/8"-16 holes are included on top center. UPC: 610079106734
• 146300 Cheese Handle with Extension The Wooden Camera 146300 Cheese Handle with Extension is a length-adjustable handle for RED Epic and Scarlet cameras. When combined together, the top handle (cheese) and the extension allow for any combination of modules to be securely bolted together by four screws. This handle and extension unit comes with four 1/4-20 x 3/8" screws. Note: Cannot be directly attached from a brain to module adapter UPC: 610079106017
• WC-150300 Rod Clamp (15mm Studio) The Wooden Camera WC-150300 Rod Clamp (15mm Studio) is a versatile, compact, and lightweight unit. It can be attached to existing 0.59" (15mm) studio rods to provide 1/4-20 and 3/8-16 mounting points. This rod clamp can also be turned over and bolted to cheeseplates, cages, and battery plates.
  • Attaches to existing 0.59" (15mm) studio rods
  • Can also be used with cheeseplates, cages, and battery plates
  • Compact and lightweight design
  UPC: 610079106277
• Battery Slide The Battery Slide from Wooden Camera is an adjustable mounting system for V-Mount, Gold Mount, QRC Gold Mount, and RED/BLUESHAPE battery plates. Multiple rows of pass-through holes allow the attachment of rod clamps, cheese plates, and other accessories.

  In order to adjust the plate's position, the user only needs to apply firm pressure to tilt it into place. Sliding the plate into position is facilitated by an adjustable thumbscrew. Both these movements make the plate ideal for adjusting counterbalance and transitioning from studio to handheld position. UPC: 610079106451
• A-Box for Red One Camera The Wooden Camera A-Box for Red One adapts industry standard balanced XLR male plugs to mini-XLR balanced plugs (female). The A-Box gives you more options in what kind of audio devices you can connect to your Red One Camera. The A-Box also comes with a bolt-on 19mm rod for attaching to any 1/4-20 threaded hole. UPC: 610079105041
• WC-145300 ARRI Style Bridge Plate (15mm) The Wooden Camera WC-145300 ARRI Style Bridge Plate (15mm) features 15mm studio offset spacing (rods spaced 100mm center to center). Its height is compatible for use with the RED ONE camera. In addition, it can be used with the Universal Baseplate to adjust the lens height on the camera, or with the Easy Riser to adjust the lens height on the RED Epic and Scarlet cameras. UPC: 610079105133
• Safety Dovetail Plate (12") The 12" Safety Dovetail Plate from Wooden Camera is an ARRI standard dovetail with a stopper screw on one end and a safety latch on the other to prevent accidental camera detachment. It features threaded 1/4-20 and 3/8-16 holes for accessory mounting and tripod attachment. The dovetail can be attached to a shoulder pad for custom handheld configurations. UPC: 610079105492

• 2 x 1/4"-20 x 3/8" Socket Cap Screw

• Limited 1-Year Warranty

• Top Handle (Cheese)

• Handle Extension

• 4 x 1/4-20 x 3/8" Screws

• 1-Year Limited Warranty

• 2 x 1/4-20 x 1/4" Screw

• 2 x 1/4-20 x 3/4" Screw

• 1-Year Limited Warranty

• 2 x 1/4"-20 x 1/4" Socket Cap Screw

• 6 x M3 x 14mm Pan Head Screws

• 4 x M3 x 12mm Pan Head Screws

• 4 x M3 x 8mm Pan Head Screws

• 4 x M3 x 8mm Phillips Flat Head Screws

• Limited 1-Year Warranty

• A-Box for Red One Camera

• 1/4-20 x 3/8" Screw

• Limited 1-Year Warranty

• 2 x Riser Screw

• 1-Year Limited Warranty

• Limited 1-Year Warranty

Also Includes

• 2 x 15mm Rod (6")
• 2 x 15mm Rod (12")
