Product description

• Unified BMPCC4K Camera Cage (Wooden Handle) Kit out your Blackmagic Pocket Cinema 4K camera for pro-style video capture with Wooden Camera's Unified BMPCC4K Camera Cage with wooden handle. The cage protects your camera on three sides while maintaining access controls on the right grip and the camera's left side. A Manfrotto quick release system on the bottom of the cage enables quick mounting and detaching from Manfrotto-compatible tripod heads and other supports. The cage's wooden top handle offers comfortable handheld operating and can be folded down for storage. The top handle can alternately be mounted to the left vertical rod as a secondary grip. Mount accessories to the 1/4"-20, 3/8"-16, and ARRI-style threads lining the top and sides of the cage. The cage incorporates a lens-adapter support system that is compatible with most Wooden Camera and Metabones 1/4"-20 adapters. The top of the Unified BMPCC4K Camera Cage leaves the space above the camera's accessory shoe unobstructed for mounting audio accessories, such as XLR adapters. An HDMI right-angle adapter and cable clamp protect the camera's HDMI port from cable snags.
  Minimalist, Accessible Design
  • This sleekly designed cage provides 1/4"-20, 3/8"-16, ARRI mounts, and Manfrotto locating slots for your Blackmagic Design Pocket Cinema Camera 4K while maintaining access to the camera's controls.
  Reversible Top Handle
  • The reversible top handle has a wooden handgrip for comfortably handholding your camera. A cold shoe at the top can be used to mount a microphone, monitor, or other accessory. The handle folds down for packing and can alternately be mounted onto the left vertical rod to provide a secondary grip.
  Manfrotto Quick Release Compatibility
  • Use the cage's Manfrotto quick release dovetail base to directly secure your camera to compatible plates and tripod heads. Simply turn the thumbscrew and depress the release pin to slide the plate backward out of the base.
  Built-In Lens Adapter Support
  • A built-in lens adapter support system provides extra support for lens adapters with a 1/4"-20 thread on the bottom, including separately available Wooden Camera PL adapters and most Metabones adapters.
  HDMI Adapter
  • A right-angle adapter and a cable clamp help to secure your HDMI cable to the camera, lessening the chance of an accidental disconnection.
  Compatible with 15mm LWS Rod Support
  • The separately available Wooden Camera Unified DSLR 15mm Baseplate can be used to add 15mm LWS rods for accessorizing your DSLR or mirrorless camera.
  UPC: 606184857050
• Unified DSLR 15mm Baseplate Expand the capabilities of your Wooden Camera Unified DSLR Cage with the Unified DSLR 15mm Baseplate. The baseplate itself holds 15mm rods at the correct placement to comply with the lightweight support (LWS) standard. Four height-adjustable posts secure to the base of the small or medium variations of the Unified DSLR Cage to ensure the correct optical axis height (the large variation of the cage has its own built-in rod clamp). The bottom of the baseplate has a dovetail clamp quick release enabling convenient tripod mounting. The dovetail clamp complies with the ARRI dovetail standard and can be easily secured to all dovetail plates of that standard, as well as Wooden Camera's own dovetails and shoulder rigs. Having multiple quick release options in a single system enables you to remove the entire rig from the tripod to go handheld, or just the camera from the rig for a minimalist setup. UPC: 606184853601
• 15mm Support Rod (12") This is a single, 12" long 15mm Support Rod from Wooden Camera for mounting accessories. It is chamfered at each end to ease sliding accessories on and off, and has a hollow interior providing for maximum strength. UPC: 610079106123
• Ultra Arm Monitor Mount (1/4"-20 to 1/4"-20, 3" Extension) This 1/4"-20 to 1/4"-20 Ultra Arm Monitor Mount from Wooden Camera features a 3" extension connecting two double ball-joint clamps. A lever in the center of each clamp locks the joints on it, and the mounting points on the ends of the arm attach to your gear easily at the turn of integrated tightening knobs. Both ends feature rubber pads for more secure support.

  The Ultra Arm system is interchangeable. Wooden Camera offers a variety of optional end-points that install into the ball sockets of the arm. These include NATO clamps, NATO rails, shoe mounts, super clamps, and even a Preston mounting bracket. Additionally, the system is compatible with many 3rd-party 25mm ball mount systems.
  Key Features
  • • Full range ball-joint articulation
    • Integrated tightening knobs
    • Rubber pads
    • Interchangeable end-points support optional NATO clamps, NATO rails, shoe mounts, super clamps, and more (see Accessories tab)
    • Also compatible with 3rd-party 25mm ball mount systems
  UPC: 606184852444
• Safety Dovetail Plate (8") The 8" Safety Dovetail Plate from Wooden Camera is an ARRI standard dovetail with a stopper screw on one end and a safety latch on the other to prevent accidental camera detachment. It features threaded 1/4-20 and 3/8-16 holes for accessory mounting and tripod attachment. The dovetail can be attached to a shoulder pad for custom handheld configurations. UPC: 610079106338

• 2 x 1/4"-20 Screws

• 3 x 1/4"-20 Threaded Support Posts

• Right-Angle HDMI Adapter

• Limited 1-Year Warranty

• 4 x 1/4"-20 Socket Cap Screws

• Limited 1-Year Warranty

• Limited 1-Year Warranty

• Limited 1-Year Warranty

• Limited 1-Year Warranty

Upload User Manual

Please enter here the link to the user manual of this product: OR Enter here the file with the user manual of this product from your computer/phone: (60MB max; Permitted formats: PDF) 0%

Technical parameters

• Unified BMPCC4K Camera Cage (Wooden Handle)

  Accessory Mounting	Multiple: 1/4"-20, 3/8"-16 Threads ARRI Accessory Mounts Manfrotto Locating Slots Cold Shoe: x 1
  Rod Mount	15 mm: x 1
  Lens Adapter Support	1/4"-20 Stud
  Dimensions (HxWxD)	8.5 x 6 x 4.5" / 215.9 x 152.4 x 114.3 mm
  Weight	15.6 oz / 442 g

  Box Dimensions (LxWxH)	8.0 x 8.0 x 2.0"

• Unified DSLR 15mm Baseplate

  Dimensions	5.5 x 4.5 x 1.5" / 140 x 114 x 38 mm
  Weight	0.5 lb / 202 g

  Box Dimensions (LxWxH)	4.55 x 2.65 x 1.8"

• 15mm Support Rod (12")

  Rod Size	15 mm
  Rod Length	12" (30.5 cm)

  Box Dimensions (LxWxH)	12.05 x 1.35 x 0.6"

• Ultra Arm Monitor Mount (1/4"-20 to 1/4"-20, 3" Extension)

  Top Mount	1/4"-20 Stud
  Bottom Mount	1/4"-20 Stud
  Points of Articulation	4
  Maximum Length	9.5" / 24.1 cm
  Weight	11.2 oz / 318 g

  Box Dimensions (LxWxH)	6.95 x 2.75 x 2.2"

• Safety Dovetail Plate (8")

  Dimensions	8.0 x 2.7 x 0.5" / 20.3 x 6.8 x 1.3 cm
  Weight	0.6 lb / 0.3 kg

  Box Dimensions (LxWxH)	9.0 x 2.8 x 0.65"
