User Manual for Xerox Phaser 6510 DN Color Laser Printer Click to enlarge the picture
Contents of the user manual for the Xerox Phaser 6510 DN Color Laser
- Product category: Laser Printers Xerox
- Brand: Xerox
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Xerox Laser Printers
 |
User manual for the Xerox Phaser 6510 DN Color Laser contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Xerox product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Xerox user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Xerox product will considerably shorten its lifespan!
|
Product description Print all your color and black-and-white documents quickly and easily with the Phaser 6510/DN Color Laser Printer from Xerox. A very capable printer, it features a maximum resolution of 1200 x 2400 dpi for sharp documents as well as impressive speeds of up to 30 ppm in simplex and up to 18 ppm in duplex mode. It features a variety of methods for handling media, including a 250-sheet standard input tray and a 50-sheet bypass tray. Also, if connected to a network through the Ethernet port, users can even print remotely from their mobile devices. Along with these features, an LCD screen is present for quickly viewing status while a front USB port allows users to print from and scan to a portable storage device. Additionally, the printer comes equipped with a standard USB 3.0 interface for direct connection to a computer. - Print directly from a mobile device using Apple AirPrint, Google Cloud Print, Mopria, Xerox Mobile Link App, and Xerox Print Service Plug-In for Android.
- Monthly duty cycle of 50,000 pages with a recommended monthly volume of 3,000 pages.
- Print features include, PANTONE Color-approved solid color simulations, N-up, fit to page, booklet printing, run black for black cartridge-only printing, covers/separators, poster printing, watermarks, overlays, banner sheets, draft mode, secure print, proof print, personal print, saved print, and RAM collation.
- Front-side USB port enables printing from and scanning to a portable storage device.
- Standard security features include Secure HTTPS (TLS), IPsec, 802.1x Authentication, S/MIME, IPv6, IP Filtering, Secure Print, Secure Fax Receive, SNMPv3, LDAP (SASL), Network Authentication, and Kerberos Authentication (Unix/Linux/Windows ADS).
UPC: 095205835359 In the Box Xerox Phaser 6510/DN Color Laser Printer 106R03473 Standard Capacity Cyan Print Cartridge 106R03474 Standard Capacity Magenta Print Cartridge 106R03475 Standard Capacity Yellow Print Cartridge 106R03476 Standard Capacity Black Print Cartridge Power Cord Software and Documentation CD Limited 1-Year Warranty More info from Xerox Table of Contents
|
Upload User Manual
Have you got an user manual for the Xerox Phaser 6510 DN Color Laser Printer in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersXerox 6510/DN Specs | | | Printing Technology | Laser | | Maximum Resolution | 1200 x 2400 dpi | | Print Speed | Simplex: 30 ppm
Duplex: 18 ppm | | First Print Out Speed | 12 seconds | | Maximum Print Size | 8.5 x 14" / 21.6 x 35.6 cm | | Duplex Printing | Yes | | Duty Cycle | Monthly: 50,000 Pages
Recommended Monthly Volume: 3,000 Pages | | Print Languages | Adobe PostScript 3
PCL 5e
PCL 6
PDF
TIFF | | | | Paper Handling | Input Tray 1
Bypass Tray
Output Tray | | Paper Sizes | Input Tray 1: 3 x 5.8" to 8.5 x 14" / 7.6 x 14.7 cm to 21.6 x 35.6 cm
Bypass Tray: 3 x 5" to 8.5 x 14" / 7.6 x 12.7 cm to 21.6 x 35.6 cm | | Media Weight | Input Tray 1: 16 lb bond to 80 lb cover / 60 to 220 gsm
Bypass Tray: 16 lb bond to 80 lb cover / 60 to 220 gsm | | Paper Capacity | Input Tray 1: 250 Sheets
Bypass Tray: 50 Sheets
Output Tray: 150 Sheets | | | | Interfaces | USB 3.0
Ethernet | | Direct Printing | USB Port | | OS Compatibility | Windows
Mac OS X, macOS
Linux | | Processor | 733 MHz | | Memory | 1 GB | | Fonts | PostScript: 136 Fonts
PCL: 88 Fonts | | | | Control Panel | LCD, buttons | | Warm-Up Time | 26 Seconds | | Power Requirements | 120 VAC (±10%), 60 Hz (±3 Hz), 12 A | | Power Consumption | Maximum: 380 W
Ready: 41 W
Sleep: 0.9 W
Off: 0.2 W | | Acoustic Noise | Sound Power
Operating: 6.8 B(A)
Standby: 4.0 B(A)
Sound Pressure
Operating: 51.9 dB(A)
Standby: 24.9 dB(A) | | Operating Conditions | Temperature: 41 to 90°F / 5 to 32°C
Humidity: 15-85% | | Storage Conditions | Temperature: -4 to 104°F / -20 to 40°C
Humidity: 15-85% | | Certifications | FCC Part 15 Class A; FCC Part 68; CE Mark applicable to Directives 2006/95/EC, 2004/108/EC and 1999/5/EC UL 60950-1/CSA 60950-1-07, 2nd Edition; NOM; GS Mark; EAC; Citrix certified; Cerner (undergoing evaluation); Apple AirPrint certification; Google Cloud Print certification; Mopria certified; Wi-Fi Alliance certified; Blue Angel; MEDITECH; ENERGY STAR; ECOLOGO; EPEAT (United States) | | Dimensions | 16.5 x 19 x 13.7" / 42 x 48.3 x 34.7 cm | | Weight | 52.5 lb / 23.8 kg | | | | Package Weight | 64.5 lb | | Box Dimensions (LxWxH) | 24.9 x 23.0 x 20.0" |
