User Manual for Yamaha DXS18 18" 1020W Active Subwoofer Click to enlarge the picture
Contents of the user manual for the Yamaha DXS18 18" 1020W Active Subwoofer
- Product category: PA Speakers Yamaha
- Brand: Yamaha
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Yamaha PA Speakers
 |
User manual for the Yamaha DXS18 18" 1020W Active Subwoofer contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Yamaha product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Yamaha user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Yamaha product will considerably shorten its lifespan!
|
Product description The DXS18 18" 1020W Active Subwoofer from Yamaha provides powerful bass reinforcement in a compact design, ideal for use alongside the DXR and DSR full-range loudspeakers. The subwoofer has a wooden enclosure with an optimized band-pass design that delivers high SPL levels with minimal distortion. The high-power 18" woofer is capable of reproducing frequencies as low as 32Hz. It is finished with a durable Line-X elastomeric coating.
The subwoofer is driven by a Class-D amplifier with a peak power rating of 1020W for clear, powerful bass. D-XSUB processing is built into the subwoofer, allowing you to choose between Normal, Boost, or Xtended LF modes. For setups consisting of two or more DXS18 subwoofers, selecting the Cardioid Mode function effectively decreases stage-side sound pressure while increasing the bottom-end output directed towards the audience, resulting in a clearer stage monitoring environment and a more pronounced bass experience out front. The rear panel has XLR input and thru connectors for compatibility with a variety of speakers and sound systems. A standard 35mm pole socket allows you to mount a full-range speaker on top of the subwoofer, while integrated handles offer convenient transportation. - Ideal for bass reinforcement alongside the DXR and DSR full-range loudspeakers
- The compact wooden enclosure has an optimized band-pass design that delivers high SPL levels with minimal distortion
- The high-power 18" woofer is capable of reproducing frequencies as low as 32Hz
- The Class-D amplifier has a peak power rating of 1020W for clear, powerful bass
- D-XSUB processing is built into the subwoofer, allowing you to choose between Normal, Boost, or Xtended LF modes
- Cardioid Mode function effectively decreases stage-side sound pressure while increasing the bottom-end output directed towards the audience
- The rear panel has XLR input and thru connectors for compatibility with a variety of speakers and sound systems
- A standard 35mm pole socket allows you to mount a full-range speaker on top of the subwoofer
- Integrated handles offer convenient transportation
- Durable Line-X elastomeric coating
UPC: 889025101103 In the Box Yamaha DXS18 18" 1020W Active Subwoofer Power Cord 3-Year Parts and Labor Warranty User Manual PDF 979.8kbccrtyrdctzeyesfbafbwt Table of Contents
|
Upload User Manual
Have you got an user manual for the Yamaha DXS18 18" 1020W Active Subwoofer in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersYamaha DXS18 Specs | Type | Active, band-pass | | Frequency Range | 32 to 120 Hz (-10 dB) | | SPL | 136 dB maximum | | Amplifier | Class-D, 1020 W dynamic, 800 W continuous | | Woofer | 18" (457 mm) cone woofer with 4" voice coil and ferrite magnet | | Controls | Level, Polarity, X-Over, Cardioid, Through/HPF Post, D-XSUB, Front LED disable, Power | | Connectors | 2 x XLR inputs
2 x XLR thru connectors (Through or HPF Post)
1 x AC power input | | Input Impedance | 20 kOhms | | Input Sensitivity | 0 dBu, +10 dBu center | | Input Level | +24 dBu max | | Low-Pass Filter | 80/100/120 Hz, 24 dB/oct | | DSP | D-XSUB: Normal, Boost, Xtended LF | | Cabinet | Wood with black painted finish and 2 metal side handles | | Mounting | 1 x Top panel 35 mm pole socket | | Power Requirements | 100 to 240 VAC, 50/60 Hz | | Power Consumption | 100 W (1/8 rating) | | Dimensions (WxHxD) | 22.2 x 26.8 x 28.4" (563.0 x 680.7 x 721.3 mm) | | Weight | 110 lb (50 kg) | | | | Package Weight | 129.6 lb | | Box Dimensions (LxWxH) | 33.0 x 32.0 x 27.0" |
