Yongnuo Speedlite YN968EX-RT for Canon Cameras

Search your instruction manual in PDF to download

User Manual for Yongnuo Speedlite YN968EX-RT for Canon Cameras

Click to enlarge the picture
Yongnuo Speedlite YN968EX-RT for Canon Cameras Contents of the user manual for the Yongnuo Speedlite YN968EX-RT for Canon Cameras
  • Product category: On Camera Flashes Yongnuo
  • Brand: Yongnuo
  • Description and content of package
  • Technical information and basic settings
  • Frequently asked questions – FAQ
  • Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
  • Authorized service for Yongnuo On Camera Flashes

Yongnuo Speedlite YN968EX-RT for Canon Cameras Yongnuo Speedlite YN968EX-RT for Canon Cameras Yongnuo Speedlite YN968EX-RT for Canon Cameras
User manual for the Yongnuo Speedlite YN968EX-RT for Canon Cameras contain basic instructions that need to be followed during installation and operation. Before starting your appliance, the user manual should be read through carefully. Follow all the safety instructions and warnings, and be guided by the given recommendations. User manual is an integral part of any Yongnuo product, and if it is sold or transferred, they should be handed over jointly with the product. Following the instructions for use is an essential prerequisite for protecting health and property during use, as well as recognition of liability on the part of the manufacturer for possible defects should you make a warranty claim. Download an official Yongnuo user manual in which you will find instructions on how to install, use, maintain and service your product.

And do not forget – unsuitable use of a Yongnuo product will considerably shorten its lifespan!



Product description

A Guide to On-Camera Flash Read More Powerful, radio-equipped, and featuring an LED video light, the Speedlite YN968EX-RT from Yongnuo aims to be one of the most versatile lighting solutions in your bag. The flash is designed with support for Canon's E-TTL / E-TTL II metering as well as compatibility with Canon's 2.4 GHz radio triggering system, while it also has optical TTL slave modes that work with both Canon and Nikon units for maximum compatibility. Also, the LED light, which features a sliding diffusion panel, can output approximately 300 lux at 3.3', making it useful for brightening up a video.

For illuminating your subjects, the YN968EX-RT offers a high guide number of 197' at ISO 100 and 105mm and can zoom from 20-105mm for covering a variety of lenses. A pull-out diffuser is available to expand coverage to wide-angle 14mm lenses. Bounce lighting is simple with -7 to +150° of tilt and 360° of rotation, and through TTL communication it has access to slow, high-speed, 1st and 2nd curtain sync. Additionally, the flash is equipped with a PC sync port, an external power port, and a USB port for firmware updates.
  • Designed to support Canon E-TTL / E-TTL II metering with support for slow, high-speed, 1st and 2nd curtain sync.
  • Equipped with Canon-compatible 2.4GHz radio triggering system that enables the YN968EX-RT to function as a TTL master or slave with Canon 600EX-RT and YN-E3-RT as well as Yongnuo YN600EX-RT and ST-E3-RT. The flash can also function as an optical slave with support for TTL communication from both Canon and Nikon systems.
  • Guide number of 197' at ISO 100 and 105mm.
  • Zoom range of 20-105mm with pull-out diffusion panel for coverage of lenses as wide as 14mm.
  • LED video light has maximum output of about 300 lux at 3.3'. A slide-out diffusion panel is available and the flash comes with a color conversion filter for changing the daylight-balanced 5500K LED to tungsten.
  • Built-in bounce card.
  • Recycle time of about three seconds at max power.
  • Runs on four AA batteries.
  • PC sync, external power, and USB ports are available.
In the Box Yongnuo Speedlite YN968EX-RT for Canon Cameras
  • Color Conversion Filter for LED Light
  • Mini Stand
  • Protecting Bag
  • Limited 1-Year Warranty
  • User Manual PDF 2.4mb Table of Contents




    Upload User Manual

    Have you got an user manual for the Yongnuo Speedlite YN968EX-RT for Canon Cameras in electronic form? Please send it to us and help us expand our library of instruction manuals. Thank you, too, on behalf of other users.

    To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
    Upload PDF user manual Upload DOC user manual
    Please enter here the link to the user manual of this product:





    OR

    Enter here the file with the user manual of this product from your computer/phone:
    (60MB max; Permitted formats: PDF)

    0%


    Technical parameters

    Yongnuo YN968EX-RT Specs

    Mount Shoe
    Guide No. 196.85' / 60 m ISO 100 at 105 mm Position
    Exposure Control E-TTL / E-TTL II, Manual
    Vari-Power 1/1 to 1/128
    Bounce Head -7 to +150°
    Swivel Head 360°
    Coverage 14 - 105 mm (Full Frame)
    Zoom Head Full Frame: 20 - 105 mm
    Off-Camera Terminal PC
    Recycle Time Approximately 3 Seconds
    Flash Duration 1/200 to 1/20000 sec
    Flash-Ready Indicator Yes
    Compensation -3 EV to +3 EV (in 1/3 EV steps)
    Slave Timing Modes Instant Sync
    Skip Preflash
    Wireless Operation Method: RF
    Distance: Up to 328.08' / 100 m
    Method: Optical Pulse
    Distance: Up to 82.02' / 25 m
    Wireless Communication Channels 15 Channels
    Wireless Groups 5 Groups
    Power Source 4 x AA Alkaline, Rechargeable NiMH Batteries
    Dimensions (W x H x D) 3.1 x 2.4 x 8.1" / 78.0 x 60.5 x 206.0 mm
    Weight 15.34 oz / 435 g
    Package Weight 1.3 lb
    Box Dimensions (LxWxH) 8.7 x 4.0 x 3.6"

    Rating

    84% users recommend this product to others. And what about you?
    Rating: 4.2 of 5

    This product has already been rated by 58 owners. Add your rating and experience with the product.
