Product description The ZIG-HVX-100 HDbaseT HDMI Extender Unit from Zigen allows you to use the output of HX-44, HX-88, or HX-1616 to display an identical image and extension of HDMI signals up to 228' by using a Cat5e cable. This receiver unit supports transmission of IR signals from a control system, providing remote control to source equipment or displays. - Allows you to use the output of HX-44, HX-88, or HX-1616 to display identical image and extension of HDMI signal up to 228' on HDTV
- Receives HDMI, audio, and RS-232 signals from a compatible transmitter unit (not included)
- Supports all frequency band IR pass-through
- Supports resolution up to 4k x 2k
In the Box Zigen ZIG-HVX-70R HDbaseT HDMI Extender Unit 12 VDC Power Adapter with Lock IR Receiver Limited 3-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Zigen ZIG-HVX-70R HDbaseT HDMI Extender Unit in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersZigen ZIG-HVX-70R Specs | Connectors | 1 x IR2 input, 3.5mm phone jack
1 x IR output, 3.5mm phone jack
1 x IR Terminal Block
1 x IR1 input, on-board
1 x HDMI Out, female Type A
1 x RJ-45, LINK
1 x F/W Upgrade, 9-pin female
1 x 12 VDC, power | | LEDs | 1 x HDCP
1 x LINK
1 x MODE
1 x POWER | | Maximum Resolution | 4k x 2k | | Transmission Range | 228' (70 m) | | Power | 12 VDC with lock | | Material | Metal | | Dimensions (L x W x H) | 5.9 x 3.1 x 1.0" (150.0 x 80.0 x 25.0 mm) | | Weight | 10.9 oz (308.0 g) | | | | Package Weight | 1.75 lb | | Box Dimensions (LxWxH) | 9.7 x 7.2 x 2.7" |
