Product description Create a personal cloud using the NAS540 4-Bay Personal Cloud Storage Server from ZyXEL that will allow you to work with documents and multimedia files from wherever an Internet connection is available. The NAS540 may also be accessed using iOS or Android smartphone apps, allowing your mobile devices to be synced with cloud platforms such as Google Drive, Memopal, ownCloud or ZyXEL's zCloud 2.0. The NAS540 is compatible with Windows, Mac, and Linux operating systems.
The NAS540 is has 4 x SATA II (3 Gb/s) drive bays that can support both 3.5" and 2.5" hard drives. Each drive bay features hot-swap support. The NAS540 is powered using a 1.2 GHz FreeScale FS1024 Dual-Core processor with 1GB of DDR3 RAM and features read speeds of up to 130 MB/s and write speeds of up to 77 MB/s. Its dual Gigabit Ethernet ports with link aggregation help to deliver increased network transfer speeds, while 3 x USB 3.0 ports provide an interface for external storage. There is also an SDXC card slot that supports SD cards with capacities up to 128GB.
For those who are concerned about data redundancy, performance, or a combination of both, the NAS540 offers support for RAID 0, 1, 5, 6, 10, 5+Hot Spare, and JBOD. It also features a built-in media server that can use apps like Bubble UPnP, Avia, Samsung TV Media, or ZyXEL zCloud 2.1 to play videos, music, and photos on your television with streaming devices such as AppleTV or Google Chromecast.
The NAS540 4-Bay Personal Cloud Storage Server operates using 100-240 VAC at 50/60 Hz. It includes a power adapter, an Ethernet cable, and is protected by a limited 2-year warranty. - myZyXELcloud / Portal to Your Devices
- Users are able to obtain a free DDNS service to create a personalized link that directs to their remote ZyXEL NAS540. Using this, a DDNS link can be established to their ZyXEL zCloud 2.0 and ownCloud application to access files from your mobile devices
- High-Performance Networking Hardware
- The 1.2 GHz dual-core CPU and 1 GB of DDR3 RAM enables the ZyXEL NAS540 to handle intensive network data management tasks. The two Ethernet LAN ports with their link aggregation capabilities deliver the high data transfer speeds on your network. The USB 3.0 ports provide external storage devices with data transfer rates of up to 4.8 Gbps, making backup tasks a snap. An SD card slot with SDXC support is included for you to transfer new photos to the ZyXEL NAS540
- Cool and Quiet Design for Silent Operations
- The ZyXEL NAS540 is designed to keep drives cool for increased product life. The 120mm fan allows it to push more air to cool down the drives without the annoying noise from high-speed, smaller fans. With 27 dB sound level from the 39.4" / 100.0cm distance, the NAS540 is whispering quiet and it gives you the freedom to place the device almost anywhere without disturbing the environment
- Storage Management & Data Protection
- Protect your personal data with RAID 1, 5, 6, or 10. With RAID support, the ZyXEL NAS540 can help protect your personal data from hard disk failures. In case any one of the disks fails, you can still access your data safely and restore the normal RAID protection with the failed disk replaced
- Intelligent Desktop, User-Friendly Graphical Interface
- The intelligent desktop offers a smooth, user-friendly graphic interface that allows you to easily view and manage the applications on your ZyXEL NAS540. Check your NAS540's health status, including CPU utilization and fan speed, with its Web GUI to help ensure the network storage is running reliably
- Stream Multimedia Contents with AirPlay or Chromecast
- Bring your favorite multimedia files on the ZyXEL NAS540 to the big screen. With apps like BubbleUPnP, Avia, Samsung TV Media, or ZyXEL zCloud v2.1, you can play your favorite videos, music, or photos on the big screen with connected streaming devices such as AppleTV or Chromecast
- USB 3.0 and SDXC Backup Support
- The USB 3.0 ports provide a fast interface for external storage with data transfer rates of up to 4.8 Gbps. An SD slot with SDXC support is included for you to transfer photos to the ZyXEL NAS540
- ZyXEL zCloud Mobile App
- With zCloud, collectively view and access all your multimedia contents on your network storage with your mobile device almost anywhere you go. ZyXEL zCloud is available for free on the Apple App Store and Google Play Store
- ownCloud
- ownCloud provides universal access to your files via the ZyXEL NSA or your mobile devices from almost anywhere
- Green
- Power Scheduling - With the power scheduling function, the NAS540 can be turned off automatically based on your usage patterns and needs to conserve power and expenses
Hard Disk Hibernation - The internal hard disks in the NAS540 can automatically spin down when there is no data transmission after a period of time
Wake-on-LAN - A new green feature dubbed "Wake-on-LAN" enables users turn on the NAS540 and access media files remotely virtually anytime and anywhere, even when the device at home is powered off UPC: 760559123666 In the Box ZyXEL NAS540 4-Bay Personal Cloud Storage Server Power Adapter Ethernet Cable Limited 2-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the ZyXEL NAS540 4-Bay Personal Cloud Storage Server in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersZyXEL NAS540 Specs | | | CPU | 1.2 GHz FreeScale FS1024 Dual Core | | Memory | 1 GB DDR3 RAM | | Drive Bays | 4 x 2.5" or 3.5" SATA II hard disks | | Hot Swap Support | Hot swappable HDD support | | Network | 2 x Gigabit Ethernet RJ-45 connectors | | USB 3.0 | 3 x USB 3.0 ports | | SD Card Slot | 1 x SDXC card reader (up to 128 GB) | | Buttons | Power button
Copy/Sync button
Reset button | | Fan | Smart Fan design | | Power Consumption | Access mode: 36.5 W (max)
Hard disk spin-down mode: 14.8 W | | Power | Input: 100 - 240 VAC, 60 /60 Hz
Output: 19 VDC, 4.74 A | | | | Network Protocol | CIFS/SMB for Windows
NFS for Linux/UNIX
DHCP client
PPPoE
Network Time Protocol (NTP) | | Network Applications | Media Server
- DLNA 1.5 media server
- UPnP AV server
- iTunes server
- SqueezeCenter support
- Photo album server | | Web Server | WebDAV
FTP server
phpMyAdmin/MySQL/PHP
RSS client & server
Print server (CIFS)
Remote Access Support (DyDNS) | | Smartphone Apps | zCloud, ownCloud | | Network Application Management | User & Group Management
Lightweight Directory Access Protocol (LDAP)
Package Management for setting up applications | | Network Security | Support HTTPS and FTPES (FTP over explicit TLS/SSL)
Encrypted NAS to NAS remote replication
Encrypted NAS to external disk archive backup | | | | Backup Support | One-touch copy/sync button for external USB-capable devices backup
Backup Planner:
- Instant/Scheduled backup
- NAS to NAS synchronization/archive backup
- Rsync
- NAS to external USB hard disk backup
Google Drive, Dropbox, Memopal, ownCloud, and NetDrive support
Apple Time Machine support | | Download / Upload Support | Auto-download from FTP/HTTP/P2P download service
Scheduled download
Auto-upload photos or videos to Flickr/YouTube/FTP server | | File System Support | Internal HDD: EXT4
External HDD: NTFS, EXT2, EXT3, EXT4, FAT32, HFS+, exFAT | | | | System Management | JBOD, RAID 0/1/5/6/10, RAID5 + Hot Spare
Online firmware upgrade
Self-Monitoring Analysis and Reporting Technology (S.M.A.R.T.)
iSCSI | | | | Power Control | Internal disk hibernation support
Scheduled power on/off/reboot
Wake-on-LAN support
System automatically resume after power outage
APC USB UPS monitoring and auto shutdown | | Thermal Management | Smart fan speed control
High temperature alert/buzzer
Auto shutdown while high temperature | | | | Minimum System Requirements | NAS Starter Utility: Windows XP and up, Mac OS X 10.5 and up
Browser: IE 11+, Firefox 20+, Google Chrome 37+, Safari 5+ | | | | Cloud Applications | ownCloud v7.x
Google Drive
Dropbox
Memopal | | Download Management | NZBGet
Transmission
pyLoad | | Other | Backup Planner
Gallery
WordPress
Tftp
NFS
SqueezeCenter
PHP-MySQL | | | | Operating Environment | Temperature: 32 to 104°F / 0 to 40°C
Humidity: 10 to 90% R.H. | | Storage Environment | Temperature: -22 to 158°F / -30 to 70°C
Humidity: 10 to 95% R.H. | | | | Certifications | Safety: CE LVD, BSMI
EMC: CE, FCC class B, C-Tick, BSMI
Others: DLNA 1.5, UPnP | | | | Dimensions | 7.48 x 8.85 x 6.29" / 189.99 x 224.79 x 159.77 mm | | Weight | 4.4 lb / 2.0 kg | | | | Package Weight | 8.45 lb | | Box Dimensions (LxWxH) | 12.7 x 11.5 x 10.6" |
