Product description With a built-in smart antenna, the WAC6303D-S Wave 2 Dual-Band Unified Pro Access Point from ZyXel has the ability to mitigate co-channel interference. In addition to mitigating interference, this dual-band access point operates on the 2.4 GHz frequency with up to 3 dBi antenna gain as well as the 5 GHz frequency with up to 4 dBi antenna gain. If that's not enough, the WAC6303D-S access point also supports the 802.11ac Wi-Fi network standard with wireless data transfer rates of up to 1300 Mb/s.
Once installed, connected clients benefit from a variety of network features designed to provide a more user friendly network experience. Beamforming technology helps to provide a more reliable connection while Multi-User MIMO technology helps allows data to be transferred more efficiently to and from the access point. If you need more than just one access point, the ZyXel WAC6303D-S is expandable using controller-managed mode. - MU-MIMO
- Stepping up from 802.11ac, the second-generation Wave 2 technology introduces Multi-User MIMO (MU-MIMO). This is an important Wi-Fi development that enables an AP to communicate with multiple clients at a time offering 300% performance for a 3x3 AP.
- Beamforming Technology
- Transmit Beamforming (TxBF) technology is another key to implementing reliable high-density Wi-Fi connections. It increases overall network transmission data rates, which benefits not only MU-MIMO clients but also all existing clients.
- Optimal Wireless Experience
- The WAC6303D-S features Smart antenna technology which is proven able to mitigate co-channel interference, and adaptively adjust antenna patterns to fit in high-density applications.
- Built for Enhanced Performance
- The WAC6303D-S is built with a high-efficiency antenna module, premium power amplifiers and low-noise elements delivering superior wireless performance over other Wave 2 access points on the market.
- Optimized Wireless Experience with Advanced Features
- To provide enhanced performance in crowded environment, the WAC6303D-S features 3G/4G interference immunity, excellent receive sensitivity, and DCS, which enlarges its service coverage for more clients and better connection quality.
- Unified Access Point
- Use standalone mode if you're a start-up, needing just few APs, or convert to controller-managed mode when your business grows and you require hundreds of APs.
- 802.11n/ac Features
- 2.4 GHz: 2x2 MIMO with two spatial stream (SU-MIMO)
5 GHz: 3x3 MIMO with three spatial stream (SU-, or MU-MIMO)
802.11ac beamforming (transmit beamforming)
Maximal ratio combining (MRC)
Low End Sensitivity Improvements (LESI)
Time Domain Channel Smoothing
20-, 40- and 80-MHz channels
PHY data rates total up to 300 Mb/s (11n) + 1300 Mb/s (11ac)
Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx)
Cyclic Delay diversity (CSD) support
Maximum Likelihood Demodulation (MLD) support
Low Density Parity Check (LDPC) support In the Box ZyXEL WAC6303D-S Wave 2 Dual Band Unified Pro Access Point Wall / Ceiling Mount Plate Limited 2-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the ZyXEL WAC6303D-S Wave 2 Dual Band Unified Pro Access Point in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersZyXEL WAC6303D-S Specs | Transmit Output Power | US (FCC) 2.4 GHz: 25 dBm
US (FCC) 5 GHz: 28 dBm | | Antenna Gain | 2.4 GHz: 3 dBi; 2x2 MIMO 5 GHz: 4 dBi; 3x3 MIMO | | Supported Data Rates | 802.11a/g: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, and 54 Mb/s
802.11n: Up to 300 Mb/s in MCS15 (40 MHz; 2 Spatial Streams; GI=400ns)
802.11ac: Up to 1300 Mb/s in MCS9 (80 MHz; 3 Spatial Streams; GI=400ns) | | Receive Sensitivity | Min. Rx sensitivity up to -103 dBm | | Interfaces | Number of 10/100/1000M LAN Ports
2 x Switch ports
Console Port
4-Pin serial
Input Power Requirements
Direct DC power or Power over Ethernet (PoE)
PoE Power Draw
16.2 W (802.3at PoE) | | WLAN | WLAN Maximum Throughput
Up to 1600 Mb/s
Fast Roaming
Pre-authentication and PMK caching
Wireless Security
WPA/WPA2-PSK
WPA/WPA2-Enterprise
WLAN access control list
EAP type
IEEE 802.1X
MAC filtering
Web authentication
Layer-2 isolation
RADIUS authentication
Microsoft AD authentication
LDAP authentication
MAC authentication
Rogue AP detection
Number of SSID
16
QoS
WMM
WMM power save
U-APSD
DiffServ marking | | Network Protocols | IPv6 support
VLANs
DHCP client | | Management | ZON Utility
Discovery of Zyxel switches, APs and gateways
Centralized and batch configurations
- IP configuration
- IP renew
- Device factory reset
- Device reboot
- Device locating
- Web GUI access
- Firmware upgrade
- Password configuration
- One-click quick association with Zyxel AP Configurator (ZAC)
Smart Connect
- Neighbor device discovery
- One-click remote management access to the neighboring Zyxel devices
Zyxel AP Configurator
- Batch AP configuration
- Batch AP firmware upgrade
- Batch AP profile backup
Zyxel Wireless Optimizer
- Wi-Fi AP planning
- Wi-Fi coverage detection
- Wireless health management
Standalone AP mode
Managed AP mode
CLI
SNMP
v2c/v3 | | Standard Compliance | Ethernet
IEEE 802.3
IEEE 802.3u
IEEE 802.11ab
IEEE 802.3au
IEEE 802.3az
IEEE 802.3af/at
PoE
IEEE 802.3af/at
WLAN
802.11b: DBPSK, DQPSK, CCK
802.11g: BPSK, QPSK, 16-QAM, 64-QAM
802.11a: BPSK, QPSK, 16-QAM, 64-QAM
802.11n: BPSK, QPSK, 16-QAM, 64-QAM
802.11ac: BPSK, QPSK, 64-QAM, 256-QAM | | Certifications | Radio
FCC Part 15C
FCC Part 15E
ETSI EN 300 328
EN 301 893
LP0002
EN 60601-1-2
EMC
FCC Part 15B
EN 301 489-1
EN 301 489-17
EN55032
EN55024
EN61000-3-2/-3
BSMI CNS13438
Safety
EN 60950-1
IEC 60950-1
BSMI CNS14336-1 | | Kensington Lock Support | Yes | | Power Supply | Input
100-240 VAC, 50~60 Hz | | MTBF | 3,960,217 hours | | Temperature & Humidity | Operating Temperature
-4 to 140°F / -20 to 60°C
Storage Temperature
-40 to 158°F / -40 to 70°C
Operating Humidity
10 to 90% non-condensing
Storage Humidity
10 to 90% | | Dimensions | 8.31 x 8.78 x 1.54" / 211 x 223 x 39 mm | | Weight | 1.8 lb / 0.8 kg | | | | Package Weight | 2.5 lb | | Box Dimensions (LxWxH) | 9.9 x 9.6 x 2.2" |
