User Manual for ZyXEL ZyWALL USG100-Plus 600 Mb s Unified Security Gateway with 50 VPN Tunnels & 6Gb Ports Click to enlarge the picture
Contents of the user manual for the ZyXEL ZyWALL USG100-Plus 600 Mb s
- Product category: Firewalls & Security Devices ZyXEL
- Brand: ZyXEL
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for ZyXEL Firewalls & Security Devices
|
User manual for the ZyXEL ZyWALL USG100-Plus 600 Mb s contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any ZyXEL product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official ZyXEL user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a ZyXEL product will considerably shorten its lifespan!
|
Product description Provided by third party: The ZyXEL USG100-PLUS, an attractive unified security gateway, can satisfy small business security needs with enterprise-class features to protect against advanced network threats. The ZyWALL USG100-PLUS is built around a powerful integrated high-performance security processor and a proven gigabit fiber architecture that provide real-time inspection to prevent the network from threats without sacrificing performance.
- Key Features
-
- Customizable zone
- Web security - content filtering
- E-mail security - anti-SPAM
- Intrusion detection and prevention
- Anomaly detection and prevention
- Application patrol (IM/P2P management)
- Bandwidth management
- Endpoint security
- User-aware management
Table of Contents
|
Upload User Manual
Have you got an user manual for the ZyXEL ZyWALL USG100-Plus 600 Mb s Unified Security Gateway with 50 VPN Tunnels & 6Gb Ports in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersZyXEL ZWUSG100PLUS Specs | | | Device Type | Security appliance | | Bundled Services | 1 year AV+IDP, AS, CF | | Width | 9.5 in | | Depth | 6.6 in | | Height | 1.4 in | | Weight | 2.65 lbs | | | | Form Factor | External | | Connectivity Technology | Wired | | Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet | | Network / Transport Protocol | L2TP, IPSec, PPPoE | | Routing Protocol | OSPF, RIP-1, RIP-2, policy-based routing (PBR) | | Remote Management Protocol | Telnet, SNMP 2c, HTTP, HTTPS, SSH, CLI | | Performance | Firewall throughput: 600 Mbps
VPN throughput (AES): 150 Mbps
Unified Threat Management (UTM) throughput: 30 Mbps | | Capacity | User licenses: unlimited
Concurrent sessions: 40000
IPSec VPN tunnels: 50
SSL VPN tunnels: 25 | | Status Indicators | Port status, power, system, USB | | Features | Firewall protection, DMZ port, routing, DHCP support, NAT support, VPN support, PAT support, SNAT support, LDAP support, VLAN support, Syslog support, traffic shaping, Stateful Packet Inspection (SPI), DoS attack prevention, content filtering, packet filtering, ALG support, dynamic DNS server, manageable, Intrusion Detection System (IDS), E-mail alert, IPv6 support, antivirus analysis, Intrusion Prevention System (IPS), URL filtering, firmware upgradable, DDos attack prevention, tunneling, anti-spam protection, IPSec NAT-Traversal (NAT-T), SSH support, DHCP server, 3G USB Dongle Support, DHCP relay, IP-MAC binding, application filtering, DHCP client, tagged VLAN | | Encryption Algorithm | DES, Triple DES, MD5, AES, IKE, SSL, DH, SHA-1, PKI, SHA-2 | | Authentication Method | Secure Shell (SSH), RADIUS, X.509 certificates, LDAP, Active Directory | | Compliant Standards | IEEE 802.1Q, X.509 | | | | Interfaces | 4 x 1000Base-T - RJ-45 (LAN / DMZ)
2 x 1000Base-T - RJ-45 (WAN)
2 x USB - Type A | | | | MTBF | 871,265 hour(s) | | Compliant Standards | ICSA IPSec certified, ICSA Firewall certified, FCC Part 15 B, EMC Class B | | | | Power Device | External power adapter | | Voltage Required | AC 120/230 V (50/60 Hz) | | Power Consumption Operational | 17 Watt | | | | Service & Support | Virus definitions update - 1 year
Intrusion definitions update - 1 year
URL database update - 1 year
Spam filter update - 1 year | | | | Min Operating Temperature | 32
Rating100% users recommend this product to others. And what about you?
This product has already been rated by 34 owners. Add your rating and experience with the product.
