The M2TND IEM Digital Half-Rack Transmitter from Lectrosonics features transmission power up to 50 mW for extended operating range and locking XLR/TRS combo connectors, that facilitate up to four channels of analog audio sources. With ultra-low latency, 24-bit audio, and two stereo-digital channels, the M2T is an IEM transmitter for professional broadcast applications.Built with a USB port for firmware updates and an IR port for fast setups, the M2T transmitter has a large, high-resolution backlit color LCD with large membrane switches for an intuitive interface visible in daylight or dimly-lit conditions. Analog signals are converted to an internal 24-bit digital format that is encoded, organized into packets, and passed to an RF modulator. The RF signal is filtered before and after amplification to suppress out-of-band noise and spurious signals.Additionally, the M2T transmitter employs a technology that provides a frequency response from 20 Hz to 15 kHz with maximum channel separation. This digital audio technology eliminates a compandor and the associated artifacts, resulting in crystal clear sound, rock-solid stereo imaging, and low distortion. In the Box Lectrosonics M2TND IEM Digital Half-Rack Transmitter (470 to 608 MHz)
