User Manual for NSI Leviton Par 56 4-Light D4DMX N3004 Mini Kit

Click to enlarge the picture
NSI Leviton Par 56 4-Light D4DMX N3004 Mini Kit Contents of the user manual for the NSI Leviton Par 56 4-Light D4DMX
  • Product category: Tungsten Lights NSI / Leviton
  • Brand: NSI / Leviton
  • Description and content of package
  • Technical information and basic settings
  • Frequently asked questions – FAQ
  • Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
  • Authorized service for NSI / Leviton Tungsten Lights

User manual for the NSI Leviton Par 56 4-Light D4DMX contain basic instructions that need to be followed during installation and operation. Before starting your appliance, the user manual should be read through carefully. Follow all the safety instructions and warnings, and be guided by the given recommendations. User manual is an integral part of any NSI / Leviton product, and if it is sold or transferred, they should be handed over jointly with the product. Following the instructions for use is an essential prerequisite for protecting health and property during use, as well as recognition of liability on the part of the manufacturer for possible defects should you make a warranty claim. Download an official NSI / Leviton user manual in which you will find instructions on how to install, use, maintain and service your product.

And do not forget – unsuitable use of a NSI / Leviton product will considerably shorten its lifespan!



Product description

The NSI Par 56 4 Light D4DMX/N3004 Mini Kit is a 4-channel programmable light system. It comes with a D4DMX 4-channel digital dimmer, which accepts up to 1200 watts per channel and 2400 watts maximum power. Also included is the N3004 Control Console, an ideal mate to the D4DMX, providing four dimming control channels, a 4-scene recordable memory and numerous chaser functions including Channel and Scene Chase, Speed and Direction Control and Audio Input. The N3004 has a master output fader and each channel has a bump button.The four Par 56's are black, rugged PAR fixtures that accept flood or spot lamps. 500-watt flood lamps are included. Also included is a 7' (2.1 m) stand with crossbar for mounting the fixtures, color frames, and gels.

PAR 56 Fixtures

  • UL Listed
  • Rigid, rolled edge frame
  • Includes frame at no extra cost

N3004 DMX Control Console

  • DMX512 output
  • 4 dimming control channels
  • 4-scene recordable memory
  • Chase Functions: 2 User-selectable Chases, Channel Chase, Scene Chase, Speed Control, Direction Control, Audio Input
  • Bump buttons for each channel or scene
  • Master output fader

D4DMX Dimming Pack

  • Microplex and DMX512 protocols
  • DMX on 3-pin receptacles
  • Data "in" and "out" provided for easy daisy-chaining of devices
  • Resettable circuit breakers (no fuses to change)
  • Simple pushbutton DMX addressing makes setup a snap
  • Bright LED display for easy, menu-driven programming
  • Versatile output channel selector lets you choose the exact number of channels you need
  • Clear operation instructions printed on back of unit for ease of use
  • 16 Pre-programmed chase patterns with chase speed and chase output level controls.
  • Input: 120V, 60Hz (15A Edison plug)
  • Output: 120V, 60Hz, 1200W per channel, 2400W Maximum
  • Built-in mounting bracket
  • Housed in rugged metal protective chassis
In the Box NSI / Leviton Par 56 4-Light D4DMX/N3004 Mini Kit (Black)
  • 4 x PAR 56 Head (Black)
  • D4-DMX 4 Channel Programmable Dimmer Pack - 3-Pin XLR (120V)
  • 3004 Dimmer DMX Control Console
  • 4 x Lamp, Medium Flood - 500 watts/120 volts - for Par 56
  • Light Stand with Crossbar
  • Gel Pack
  • Limited 1-Year Warranty
  • Table of Contents




    Upload User Manual

    Have you got an user manual for the NSI Leviton Par 56 4-Light D4DMX N3004 Mini Kit in electronic form? Please send it to us and help us expand our library of instruction manuals. Thank you, too, on behalf of other users.

    To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
    Upload PDF user manual Upload DOC user manual
    Please enter here the link to the user manual of this product:





    OR

    Enter here the file with the user manual of this product from your computer/phone:
    (60MB max; Permitted formats: PDF)

    0%


    Technical parameters

    NSI / Leviton Par 56 Specs

    Rating Each Fixture: Up to 500 W
    Socket (Lampholder) Mogul end-prong
    Lens (Condenser) In bulb of choice
    Reflector (Mirror) None
    Mounting C-clamp
    Yoke Flat bladed fork
    Cable 3' / 1 m, household Edison plug
    Focusing Depends on bulb in use
    Weight Each Fixture: 4.6 lb / 2.1 kg
    Dimmer: 9 lb / 3.2 kg
    Control Console: 2.4 lb / 1.5 kg
    Dimensions Each Fixture: 14.5 x 9.8 x 9.8" / 36.8 x 25 x 25 cm
    Dimmer: 10.2 x 7.5 x 2.6" / 26 x 19 x 6.7 cm
    Control Console: 9 x 6.7 x 2.2" / 23.2 x 17 x 5.6 cm
    Kit Weight 32.4 lb / 14.7 kg
